Material and spec
| Coupling | Push-pull |
| Shell material | Anodized aluminium |
| Insert material | PPS,max temperature 260 ℃ |
| Contact material | Brass with gold plating |
| Termination | Solder: SA6, SA8, SA10, SA12, SA16, SA20, SA24, SA28 Crimp: SA16, SA20, SA24, SA28 Screw: SA20, SA24, SA28 |
| Cable outer diameter range | SA6: I: 2-3mm, II:3-4mm(omit) SA8: I: 3-4mm, II:4-5mm(omit) SA10: I: 3-4mm, II:4-6.5mm(omit) SA12: I: 4-6.5mm(omit), II: 5-8mm SA16: I: 5-8mm(omit), II: 8-12mm SA20: I: 5-9mm, II: 8-12mm(omit) SA24: 10-14mm SA28: I: 9-13mm, II: 13-16mm(omit) |
| IP rating | IP67 |
| Mating cycle | 500 USB: 1000 |
| Temperature range | -40°C~+ 85°C |
| Insulation resistance | 2000MΩ |
