Material and spec
| Coupling | Bayonet |
| Shell material | PC, Nylon66, fire resistance: V-0 |
| Insert material | PPS, max temperature 260 ℃ |
| Contact material | Brass with gold plating |
| Termination | Solder: SY11, SY13, SY17, SY21, SY25, SY29 Crimp: SY17, SY21, SY25, SY29 Screw: SY21, SY25, SY29(Φ2.5,Φ3,Φ3.5mm contact) |
| Cable outer diameter range | SY11: I:3-4mm, II:4-6.5mm (omit) SY13: I: 4-6.5mm(omit), II: 5-8mm SY17: 6-10mm SY21: I: 4.5-7mm, II:7-12mm(omit), III:5-9mm SY25: I: 10-14mm(omit) SY29:I:9-13mm, II:13-16mm (omit) |
| IP rating | IP67 |
| Mating cycle | 500 |
| Temperature range | -40°C~+ 85°C Signal, Data: -20°C~+70°C |
| Insulation resistance | 2000MΩ |
