Material and spec
| Coupling | Push-pull |
| Shell material | Brass with chrome plating |
| Insert material | PPS max temperature 260 ℃ |
| Contact material | Brass with gold plating |
| Termination | Solder: SF6, SF8, SF10, SF12, SF16, SF20 Crimp: SF16, SF20 Screw: SF20(Ø2.5mm contact) |
| Cable outer diameter range | SF6: I: 2-3mm, II:3-4mm(omit) SF8: I: 3-4mm, II:4-5mm(omit) SF10: I: 3-4mm, II:4-6.5mm(omit) SF12: I: 4-6.5mm(omit), II: 5-8mm SF16: I: 5-8mm(omit), II: 8-12mm SF20: I: 5-9mm, II: 8-12mm(omit) |
| IP rating | IP67 |
| Mating cycle | 500 |
| Temperature range | -40℃~+ 85℃ |
| Insulation resistance | 2000MΩ |
